NEC Express5800/320Fa-L
(N8800-082F,N8800-082AF) |
NEC Express5800/320Fa-LR
(N8800-083F,N8800-083AF) |
| CPU |
Type |
Intel Xeon Processor x 1 |
| Clock/second cache |
3.2GHz/2MB |
| Number of processors |
1 processor (the number of processors installed per module) |
| Maximum |
Up to 2 processors (the number of processors installed per module) |
| Chipset |
GeminiEngine (NEC original chipset) |
| Memory |
Standard |
None |
| Maximum |
6GB (The standard DIMM must be replaced.) |
| Expansion unit |
2 DIMMs (512MB x 2/ 1GB x 2) |
| Memory module |
DDR400 SDRAM DIMM (Registered Type) |
| Error check |
ECC |
| Graphics (VRAM) |
ES1000 (32MB) |
Auxiliary
input
device |
Floppy disk (standard) |
3.5-inch drive x 1 (USB) |
| Hard disk (standard) |
None |
| Hard disk (maximum) |
1.8TB (300GB x 6)
The user area is reduced to a half of the physical capacity due to software mirroring. |
| CD-ROM (standard) |
ATAPI interface x 1 (Load on tray type, x24 speed) |
| File bay |
5.25 inch |
2 slots |
None |
| 3.5 inch |
6 slots |
Additional
slot |
PCI, 64-bit |
4 slots (Low profile) |
| LAN interface |
1000BASE-T/100BASE-TX/10BASE-T (2 ports) |
External
interface |
USB |
4-pin connector (3 ports) Keyboard occupies one port. |
| Network |
RJ-45 (4 ports) |
| Display |
MINI D-sub 15-pin (1 port) |
| Cabinet design |
Tower type |
Rack-mount type |
| External dimensions |
310 mm (w) x 543 mm (h) x 715 mm (d) |
485 (w) x 177 (h) x 635 (d) mm |
| Weight |
59 kg (Max. 66 kg) |
38 kg (Max. 47kg) |
| Power supply |
100 to 120 VAC +- 10%, 200 to 240 VAC +- 10%, 50/60 Hz +- 1 Hz |
| Power consumption |
829 VA, 819 W |
Environmental
requirements |
In operation |
Temperature 10 to 35°C
Humidity 20 to 80% RH (non-condensing) |
| In storage |
Temperature -10 to 55°C
Humidity 20 to 80% RH (non-condensing) |
| Supported OS |
Microsoft® Windows® Server 2003 SP1 |
|
NEC Express5800/320Fa-L
(N8800-090F) |
NEC Express5800/320Fa-LR
(N8800-091F) |
| CPU |
Type |
Intel Xeon Processor x 1 |
| Clock/second cache |
3.2GHz/2MB |
| Number of processors |
1 processor (the number of processors installed per module) |
| Maximum |
Up to 2 processors (the number of processors installed per module) |
| Chipset |
GeminiEngine (NEC original chipset) |
| Memory |
Standard |
None |
| Maximum |
6GB (The standard DIMM must be replaced.) |
| Expansion unit |
2 DIMMs (512MB x 2/ 1GB x 2) |
| Memory module |
DDR400 SDRAM DIMM (Registered Type) |
| Error check |
ECC |
| Graphics (VRAM) |
ES1000 (32MB) |
Auxiliary
input
device |
Floppy disk (standard) |
3.5-inch drive x 1 (USB) |
| Hard disk (standard) |
None |
| Hard disk (maximum) |
1.8TB (300GB x 6)
The user area is reduced to a half of the physical capacity due to software mirroring. |
| CD-ROM (standard) |
ATAPI interface x 1 (Load on tray type, x24 speed) |
| File bay |
5.25 inch |
2 slots |
None |
| 3.5 inch |
6 slots |
Additional
slot |
PCI, 64-bit |
2 slots (Low profile) |
| LAN interface |
1000BASE-T/100BASE-TX/10BASE-T (2 ports) |
External
interface |
USB |
4-pin connector (3 ports) Keyboard occupies one port. |
| Network |
RJ-45 (4 ports) |
| Display |
MINI D-sub 15-pin (1 port) |
| Cabinet design |
Tower type |
Rack-mount type |
| External dimensions |
310 mm (w) x 543 mm (h) x 715 mm (d) |
485 (w) x 177 (h) x 635 (d) mm |
| Weight |
59 kg (Max. 66 kg) |
38 kg (Max. 47kg) |
| Power supply |
100 to 120 VAC +- 10%, 200 to 240 VAC +- 10%, 50/60 Hz +- 1 Hz |
| Power consumption |
829 VA, 819 W |
Environmental
requirements |
In operation |
Temperature 10 to 35°C
Humidity 20 to 80% RH (non-condensing) |
| In storage |
Temperature -10 to 55°C
Humidity 20 to 80% RH (non-condensing) |
| Supported OS |
MIRACLE LINUX V4.0 SP1 |
|
NEC Express5800/320Fa-M
(N8800-088F,N8800-088AF) |
NEC Express5800/320Fa-MR
(N8800-089F,N8800-089AF) |
| CPU |
Type |
Intel Xeon Processor x 1 |
| Clock/second cache |
3.8GHz/2MB |
| Number of processors |
1 processor (the number of processors installed per module) |
| Maximum |
Up to 2 processors (the number of processors installed per module) |
| Chipset |
GeminiEngine (NEC original chipset) |
| Memory |
Standard |
None |
| Maximum |
12GB (The standard DIMM must be replaced.) |
| Expansion unit |
2 DIMMs (1GB x 2/ 2GB x 2) |
| Memory module |
DDR400 SDRAM DIMM (Registered Type) |
| Error check |
ECC |
| Graphics (VRAM) |
ES1000 (32MB) |
Auxiliary
input
device |
Floppy disk (standard) |
3.5-inch drive x 1 (USB) |
| Hard disk (standard) |
None |
| Hard disk (maximum) |
1.8TB (300GB x 6)
The user area is reduced to a half of the physical capacity due to software mirroring. |
| CD-ROM (standard) |
ATAPI interface x 1 (Load on tray type, x24 speed) |
| File bay |
5.25 inch |
2 slots |
None |
| 3.5 inch |
6 slots |
Additional
slot |
PCI, 64-bit |
6 slots (Low profile) |
| LAN interface |
1000BASE-T/100BASE-TX/10BASE-T (2 ports) |
External
interface |
USB |
4-pin connector (3 ports) Keyboard occupies one port. |
| Network |
RJ-45 (4 ports) |
| Display |
MINI D-sub 15-pin (1 port) |
| Cabinet design |
Tower type |
Rack-mount type |
| External dimensions |
310 mm (w) x 543 mm (h) x 715 mm (d) |
485 (w) x 177 (h) x 635 (d) mm |
| Weight |
58 kg (Max. 64 kg) |
38 kg (Max. 44kg) |
| Power supply |
100 to 120 VAC +- 10%, 200 to 240 VAC +- 10%, 50/60 Hz +- 1 Hz |
| Power consumption |
829 VA, 819 W |
Environmental
requirements |
In operation |
Temperature 10 to 35°C
Humidity 20 to 80% RH (non-condensing) |
| In storage |
Temperature -10 to 55°C
Humidity 20 to 80% RH (non-condensing) |
| Supported OS |
Microsoft® Windows® Server 2003 SP1 |
